Designed to Support Designers

Professional diagrams and renderings built using real photometric data to support confident design, sales, and installation.

Why choose a Sterling Luminaires Diagramming & Rendering Package?

Untitled_design_12

Real IES Data

Every rendering is built using the actual IES photometric files from Sterling luminaires. Light levels, beam spreads, and distribution patterns are calculated exactly as the luminaires perform in the field. This ensures each rendering reflects true output and behavior, allowing you to evaluate balance, coverage, and intent with confidence, without approximation, interpretation, or artificially generated light.
b-roll_drawing_close_office_05_28_2025_v2_96edff28-7f06-4c95-a833-da96114e82f7

Trained Lighting Designers

Every project is personally reviewed by trained lighting designers who study the architecture, landscape, and intended visual hierarchy before creating or refining the design. This is not an automated or template-driven process.
 Whether starting from photos, plans, or an existing layout you provide, the design is thoughtfully developed by experienced professionals to ensure the placement, balance, and intent align with real-world installation and performance.
Untitled_design_13_64b90b35-f9c8-4c2c-8445-ecb658823c8b

Comprehensive Diagrams and Renderings

Each project includes clear, detailed diagrams and realistic renderings that communicate the full design intent. These materials provide everything needed to present the concept to your client, guide your installation team, and ensure fixtures are placed exactly as intended. They also serve as professional documentation suitable for planning approvals, HOA submissions, and project records.

Diagramming & Rendering Assistance Package

$225.00
- {price}%
Package Options
  • Base Package
